GUA Junction and Pulling Box
Control Stations and Control Panels, Electrical SystemsEx d IIC aluminium junction and pulling box for zone 1/2 – 21/22
Benefits
- IP 66
- Cast iron on request
- Possibility of internal anticondensate paiting
-
Description
Marking
ATEX:
(Ex II 2 G) Ex db IIC T6…T3
(Ex II 2 G) Ex eb IIC T6.. T3
(Ex II 2 D) Ex tb IIIC T85°C…T200°C
IECEx:
Ex db or eb IIC T6 or T5 or T4 or T3 Gb
Ex tb III C T85°C or T100°C or T135°C or T200°C Db IP66
Ambient Temperature
-60 °C to +130 °C
Certification
-
ATEX
- EN
- IT
-
IECEx
- EN
-
ECASEx
- EN
-
INMETRO
- PT
-
NEC505
- EN
-
CCOE-PESO (Ex d)
- EN
-
CCOE-PESO (Ex e)
- EN
Flameproof enclosures GUA series are designed to be installed in industrial plants, where potential hazardous atmos-pheres occur.
These areas are either classified as zone 1 and 2 or as zone 21 and 22.
These enclosures are designed to contain terminals or to be installed as pulling boxes
Technical Data
| Protection class | IP 66 (IEC/EN 60529) |
|---|---|
| Material | Enclosure material:Copper free aluminium alloy ( 0.1% copper) Surface treatment: External powder type painted RAL9006 Internal anti-condense painting RAL2004 (optional) |
| Weight | see data sheet |
| Dimensions | see data sheet |
| Accessories | O-Ring silicon rubber gasket |
| Quantity of cable entries | see data sheet |
| Voltage | Max. rated voltage : 750V (AC) / 750V (DC) |
| Current | Max. rated current : 40A |
| Imapct test | 7 Joule for metallic parts of enclosure (Passed) |
Manuals/Operating Instructions/Guides
-
ATEX – Instruction for use
- EN
- IT
-
IECEx – Instruction for use
- EN
- IT
-
INMETRO – Instruction for use
- EN
- PT
-
NEC505 – Instruction for use
- EN
Declarations
-
ATEX – Declaration of conformity
- EN
-
IECEx – Declaration of conformity
- EN
- IT
Data Sheets
Data sheet – Flameproof enclosures GUA-EAHF
